High-speed handling

• 1,800 packages per hour at maximum. (for 130kg loads)
• Improvement of 20% compared with the conventional model.
• High performance based on the large capacity motor and the enhanced optimized motion control
* Motion pattern: 400mm in vertical direction, 2,000mm in horizontal direction and 60 degree in swivel movement.

Flexible palletizing

• Flexible layout of work-piece of various shapes/sizes due to the wide operation range
(Pallet area size: 1,600mm squares and the hight is up to 2,212mm)
• Hadling with suitable hand (option) for the work-piece is available

Compact layout

• The large motion range and the space saving design reducing the interference amount realize the compact and flexible design of the equipments

Easy operation

• Easy setup due to an interactive interface.
• Easy programming by interactive program generator.
